OCIMF-Compliant Single Point Mooring (SPM) System
A 12-strand double-braid nylon hawser engineered for offshore tanker offloading at single point mooring and CALM buoys. Both ends carry PU-coated metal protective sleeves, and inline buoyancy floats keep the line on the surface and clear of the seabed — all manufactured to OCIMF standards.
Representative specification for the main SPM hawser. End fittings, float spacing, length and certified documentation are configured per terminal.
| Construction | 12-strand double braid |
| Material | Nylon (Polyamide) |
| Density | 1.14 g/cm³ (sinking core) |
| Melting point | 218–258 °C |
| Abrasion resistance | Excellent |
| UV resistance | Good |
| End protection | Metal sleeve + PU coating |
| Buoyancy | Inline floats (fixed spacing) |
Indicative Minimum Breaking Force for the nylon double-braid main hawser. Grommet and tail configurations available on request.
| Diameter mm | MBL · tonnes | MBL · kN |
|---|---|---|
| 64 | 160 | 1,570 |
| 72 | 200 | 1,962 |
| 80 | 245 | 2,403 |
| 88 | 295 | 2,894 |
| 96 | 350 | 3,434 |
| 104 | 410 | 4,022 |
| 112 | 470 | 4,611 |
| 120 | 540 | 5,297 |
Indicative Minimum Breaking Force by diameter. Other sizes, grades and certified break-test documentation available on request — confirm final selection with our technical team.
The complete single point mooring package — hawser, tails and connecting hardware.
The primary mooring line between buoy and tanker — 12-strand nylon double braid with PU-coated end sleeves and inline buoyancy floats.
High-elongation mooring tails in 11 m or 22 m lengths with galvanised steel shackles — the compliant interface between hawser and vessel chain stopper.
Use the specification above directly in our calculators.
